It is exchangeable with 4153 recliner.
The
ottoman adopts the design of wide heavy gauge links and built-in
articulating elevated mid-ottoman. Profile shape designed for
safety and appearance without pinch points. Articulating designs
allows use of wider & higher mid-ottoman for elimination of
entrapment areas and for leg support.
-
The system adopts
the geometrically balanced design to balance chair operation. It
is consistent and easy for operation by any person. The
occupant's weight is used to balance operation. Meanwhile it
controls the sitting position and reclining position. Springs
here are only used for locking and the initial start of the
opening.
-
The customer has
several options as to how to activate the mechanism. There are
cable style, outside handle style and inside handle style. Easy
operation. Customer can choose to use handle or lever activation
to open the mechanism and the color of the handle or lever.
Slight footrest pressure will allow closing the ottoman.
-
The system uses
direct drive with double locks. The direct drive with double
over-centre locks enables maximum synchronization of side
positive locking of both sides. Square drive tube connects to
and controls both left and right sides. Ottoman is locked closed
on both sides.
-
Minimum stack-up
design. The adoption of the flatter links and wider base
mounting points enables greater bending resistance and greater
stability and strength. It improves weight capacity and
durability. The mechanism base width is closer to seat width
while maintaining sufficient clearance between links to
eliminate possibility of interference.
-
Metal rocker base
assembly. The welded base assembly ensures the maximum strength
and durability. All tubular cross members for maximum resistance
to twisting and bending. Flat plastic glide allow base to be
longer for resistance to tipping over without interfering with
chair frame when rocking backward more rock and shorter frames.
7 base positions and 3 cam positions for balancing rock.
-
The system uses
the extended life rivet joints design. All rivet joints have
either acetal or bronze rivet bushing and acetal spacers to
eliminate any steel to steel contact. No metal to metal noises
when links contact nylon stop pins.
-
Interchangeable
on wood frame design. The wood frames designed for the rocker
recliner, motorized lift are all interchangeable.
